Standard, pre-engineered channel style beam clamps anchor to a building’s beam structure and offers a safe and predictable method for suspending objects from overhead. This channel style beam clamp is adjustable, mounts flush underneath the beam’s flange and provides a centrally located mounting hole for use with many types of connections, including 5/8″ all-thread and bolts for use in securing yokes, U-Brackets, truss clamps, Unistrut etc. Use the BC3-8-0 channel style beam clamp to provide a load rated overhead rigging point from structural I-Beams with flange widths ranging between 3″ and 8″ (76203mm). This beam clamp model provides a fast, easy and safe way to rig direct loads from overhead and a hand wrench is all that is required to secure this clamp.
Features:
- Center hole for 5/8″ diameter threaded rod.
- Center hole for 1/2″ and 1-1/2″ dia. pipe adapters
- Provides safe load-rated suspension
- Clamps securely to beam flange widths from 3″ – 8″
