USB Audio Interface
- With up to 48 kHz sample rate
- 4 inputs and 4 outputs with cinch connections
- 18-bit A / D converter
- 20-bit D / A converter
- -10 dBV input and output level (unbalanced)
- Optical S / PDIF digital output with mini plug connection
- Headphone output with 3.5 mm jack socket
- With integrated 60 mW amplifier
- ASIO 2.0 / CoreAudio support / MME and WDM support (4 input / 4 output channels)
- Standard USB connection to PC or Mac
- Compatible with Windows and Mac OS
- Compact and lightweight aluminum housing
- Dimensions: 120 x 70 x 20 mm
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceMarch 2007
- Item number111455
- Sales Unit1 piece(s)
- Recording / Playback Channels 4×4
- Number of Mic Inputs 0
- Number of Line Inputs 4
- Instrument Inputs 0
- Number of Line Outs 4
- Headphone Outs 1
- Phantom Power No
- Number of S/PDIF Connectors 0
- Number of ADAT Connectors 0
- Numer of AES/EBU Connectors 0
- Number of MADI Connectors 0
- Ethernet 0
- Other Connectors None
- MIDI interface No
- Word Clock No
- Max. Sampling Rate in kHz 48 kHz
- Max. Resolution Rate in Bits 16 bit
- USB Bus-Powered Yes
- Incl. power supply No
- USB Version 1.1
- Width 120 mm
- Depth 70 mm
- Height 20 mm
- Connection Format USB port Mini B
- Included in deliveryUSB-A to Mikro-USB Cable
