On-screen talent wears a lavalier microphone and transmitter.
View larger The MXL FR-500WK kit includes a belt pack transmitter and camera-mountable receiver.
View larger
MXL FR-500WK Wireless Interview Kit
The FR-500WK makes it simple to record your subject virtually anywhere. This compact kit is perfect for journalists and videographers covering events on location. An included lavalier mic and transmitter are worn by the subject. With 64 channels to choose from, the matched transmitter and receiver ensure flawlesstransmission of audio from your subject’s microphone to the camera.
Receiver
The FR-500WR receiver can be mounted directly onto the hot shoe mount of a DSLR camera. The receiver can be plugged into a mixer or recording device using the included 1/8″ to XLR male cable and/or 1/4″ adapter. A headphone jack is built into the receiver for audio monitoring. Features include: built-in speaker, 1/8″ (3.5 mm) audio out jack, and line out. Receiver includes hot shoe mount, 1/8” to 1/8” cable, 1/8” to XLR male, and ¼” adapter.
Transmitter
The FR-500WT transmitter is worn by the talent. A lavalier microphone is included. The transmitter can also be used with an optional handheld microphone (sold separately) when a microphone is desired in the shot.
Specifications
- Frequency Range: 566.25 – 589.75 MHz
- Frequency Response: 40 Hz-18 kHz
- Operating Range: Up to 280m
- Channels: 64 (4 groups of 16 channels)
- Controls: Power On/Off, Channel Selection, Volume Control, Group Selection, Boost
- Battery: Each unit requires 2 x AA (not included)
- Dimensions (Each): 62mm(W) x 20mm(D) x 97mm(H)
